Dookyu Crown 43ft CE Aluminum Fire Rescue Patrol Vessel

Product Advantage

• CE certified fire rescue patrol – Certified under EU Directive 2013/53/EU for commercial rescue craft. Cat A ocean-going certification for unlimited voyages.

• Rapid intervention aluminum craft – 0-30 knots in under 45 seconds; rapid docking system for 2-minute crew deployment upon arrival.

• Deck mounted foam monitor – 1,800 L/min foam/water monitor with 150m throw. Foam tank capacity 400L for class B fires. Remote control from helm or handheld.

• Emergency medical treatment area – 4 sq meters enclosed cabin with climate control. Includes two stretchers, oxygen, suction, and paramedic seat.

• Twin screw diesel propulsion – Twin 250HP common-rail diesels; CPP propellers for precise low-speed handling. Range 450 nm at 22 knots.

• All weather rescue operation – Heated windows and cabin; self-righting hull (capsize recovery under 10 seconds). Operate in Beaufort 9 conditions.

• Crash worthy aluminum structure – 5083-H116 alloy with 10mm bottom, 8mm sides. Meets collision standards for high-speed impact at 20 knots.

• Integrated command and communication – VHF/DSC, UHF, satellite phone, AIS, radar, and thermal camera all integrated into one touchscreen helm.

Technical Parameters

Product Uses

• Port and terminal fire response – Rapid intervention aluminum craft reaches tanker berths or LNG terminals. Deck mounted foam monitor is specifically designed for class B fuel fires.

• Search and rescue at sea – Locate and recover survivors in heavy weather. All weather rescue operation capability ensures response even in storms. Thermal camera detects people in water.

• Marine medical evacuation – Emergency medical treatment area provides advanced life support. Transport patients from vessels to shore with on-board ECG and oxygen.

• Coastal security and anti-smuggling – Integrated command and communication links with national coast guard network. High-speed interception with reinforced bow for boarding.

• Harbor master and port state control – Multi-mission patrol: inspect vessels, enforce regulations, and escort large ships. Crash worthy aluminum structure withstands close-quarters maneuvering.

• Disaster relief operations – Deploy after earthquakes, tsunamis, or hurricanes. Carry supplies, medical teams, and rescue equipment to cut-off coastal communities.

Product Operate Guide

Pre-deployment checklist for this CE certified fire rescue patrol vessel. Inspect crash worthy aluminum structure for any impact damage. Check twin screw diesel propulsion – fuel, oil, coolant, and transmission fluids. For all weather rescue operation, confirm heating and de-icing systems are operational. Test deck mounted foam monitor with water first – check rotation, elevation, and pump pressure. Stock emergency medical treatment area with standard trauma supplies and oxygen. Activate integrated command and communication and test all links. Start engines, allow 5-minute warm-up (or until coolant reaches 50°C). As a rapid intervention aluminum craft, maintain 25-30 knots en route to incidents. Upon arrival, deploy crew – the side boarding doors allow rapid egress. For fire operations, select foam or water and begin suppression from upwind. For rescue, deploy the stern recovery ramp. Post-mission: flush fire pump and engines. Clean medical area. Weekly: test all emergency systems and foam proportioner. Monthly: verify navigation lights and sirens. Annual CE recertification inspection required.
